CageMaker PRCG is a web-based parametric rack cage generator designed for creating custom rack cage designs tailored to specific device dimensions. It addresses the need for precise, device-specific enclosures, allowing users to input measurements such as depth, width, and height to generate a fitting cage. The tool operates directly in the browser, utilizing a Java-based port of OpenSCAD, which means users do not need to install OpenSCAD locally to use its core features.
Users can specify the size of the rack for mounting the cage, with default support for full-width cages in 10-inch racks, as well as options for partial-width cages that can be bolted together for wider racks. The platform also accommodates various micro- and mini-rack systems. For greater flexibility, CageMaker PRCG allows cages to be generated in full or half rack-unit heights, and includes options to split cages into two halves for smaller 3D printer build volumes. Additional features include settings for extra support and alignment pin holes, enhancing the stability and assembly of the final printed cage.
Once the desired parameters are set, users can render the 3D object through the integrated OpenSCAD Playground. The completed design can be downloaded as an STL file for 3D printing. The tool also supports exporting in GLB, OFF, and 3MF formats, providing compatibility with a variety of slicers and workflows. Documentation and a quick-start guide are available to assist users in the design process.
CageMaker PRCG is accessible via the web and is funded by its author through donations. The project is attributed to WebMaka, with OpenSCAD Playground provided by Olivier Chafik. The platform is intended for individuals needing custom rack cage solutions, such as makers, engineers, or hobbyists working with 3D printing and rack-mounted devices.
CageMaker PRCG sits in PulseGate's 3D, motion & animation category. Enabling users to easily design and generate custom rack cages for devices without CAD expertise. CageMaker PRCG is a consumer product aimed at makers, 3D printing enthusiasts, engineers. CageMaker PRCG costs nothing to use. It runs on the web.
CageMaker PRCG first shipped in 2025. The project is developed in the open on GitHub with 422 stars and 5 commits in the last 90 days. Among its 5 catalogued features are parametric design, rack size customization, and openSCAD integration.
